OSFP 2*FR4 transceiver is a high-quality optical transceiver designed for 800
Gigabit Ethernet links over 2 km of single-mode fiber. This 800G FR 2km
transceiver features 8 independent electrical input/output channels, each
operating at speeds up to 106.25 Gbps. Comprising two transmitter/receiver
units, each unit functions across a set of 4 wavelengths on the ITU G.694.2
CWDM grid near 1300 nm. The transceiver’s electrical interface conforms to the
800GAUI-8 standard defined by IEEE 802.3ck and is also compliant with the OSFP MSA. It is suitable for various network applications, including Internet
protocol switches and routers.
Hot-pluggable
OSFP form factor
Supports
850Gb/s aggregate bit rate
Power
dissipation <16W
Commercial
case temperature range of 0°C to 70°C
Single
3.3V power supply
Maximum
link length of 2km on Single Mode Fiber (SMF)
Aligned
with IEEE 802.3cu
8x100G
PAM4 EML-based CWDM transmitter
8x100G
PAM4 retimed 800GAUI-8 electrical interface
Dual LC receptacles
I2C
management interface
RoHS
compliant
