HD Pre-Terminated Trunk Cable
High Density MPO / LC Pre-Terminated Trunk Cable
JTOPTICS® MPO Trunk Cables are engineered for high-density
network setups where known cabling distances and efficient space utilization
are crucial. These cables are ideal for backbone cabling within and between
buildings. They help reduce cable volume and improve airflow conditions,
offering a cost-effective alternative to labor-intensive field termination. MPO
trunk cables are available with fiber counts of 12, 24, 48, up to 72 fibers.
The connectors can be either male with pins or female without pins, and the
fibers can be connected using three methods: Method A (straight-through),
Method B (reversed), and Method C (pair-flipped). These cables can be
customized for any fiber mode, fiber count, and configuration.
MPO trunk cables utilize MPO connectors on each end to
maximize physical density. They perform well in high-density environments,
ensuring consistent signal quality due to their low insertion loss and high
return loss. The cables feature a simple push/pull mechanism for easy insertion
and removal. MPO stands for Multifiber Termination Push On.
100% pre-terminated and tested in factory to ensure
transfer performance
Rapid configuration and networking, reduce installation
time
Supports 40G and 100G network applications
Jacket material: LSZH, OFNR, OFNP available
Supports up to 12F, 24F, 48F, 72F, customized products are
available
Plug-and-Play Precision: MPO Pre-Terminated Trunk Cables for High-Speed Networks
Ensuring Excellence: MPO Cable Quality Testing
Insertion Loss Testing
Ensures minimal signal loss for flawless data transmission.
Return Loss Testing:
Verifies low reflection for maximum signal efficiency.
Polarity Check:
Confirms correct fiber alignment for reliable connections.
Endface Inspection:
Inspects connector endfaces for cleanliness and precision.
Mechanical Durability:
Tests cable strength to withstand environmental and physical stress.
